Our company has meticulously designed, developed and manufactured this innovative high-efficiency mixing equipment by assimilating advanced domestic and international technology. It supersedes traditional two-dimensional movable mixers, offering superior mixing uniformity. This machine excels even when processing particles and powdery materials with varying temperatures, softness levels, and specific gravities. Fully compliant with GMP requirements, its safety is ensured through remote control capabilities and the use of imported stainless steel for all material-contact parts.
This versatile machine is widely employed for unit operations involving diverse materials across industries such as pharmaceuticals, chemicals, and food processing.
Model | HD-100 | HD-200 | HD-400 | HD-600 | HD-800 | HD-1000 |
barrel volume(L) | 100 | 200 | 400 | 600 | 800 | 1000 |
max.loading volume(L) | 75 | 160 | 320 | 480 | 640 | 800 |
max.loading weight(KG) | 50 | 100 | 200 | 300 | 400 | 600 |
Splidle speed(r/min) | 0-15 | |||||
Motor power(KW) | 1.5 | 2.2 | 4 | 5.5 | 7.5 | 11 |
Overall dimention (mm) | 1500*1200*1500 | 1750*1400*1800 | 2200*1550*1880 | 2250*1850*2100 | 2500*2000*2200 | 2700*2200*2250 |
Weight (kg) | 500 | 800 | 1200 | 1500 | 2000 | 2500 |
Three-dimensional movable mixer has particular function in motion, so to say, special motion directions such as rotation, intersection, up-side-down, tumbling and etc.
During operation, all material in the mixing drum can be in self-rotation and diffusion under both rotations without centrifugal force and be free of such phenomenon as gravity, segregation, separation and accumulation
It has both functions of frequency control and constraint speed control and specially -designed butterfly valve features high tightness, free leakage.
