The bottles fitted with aluminum foil pass beneath the inductive head, where the foil heats rapidly as it absorbs the energy emitted. This heat melts the plastic film bonded to the foil, causing it to adhere securely to the bottle mouth and achieve an effective seal.
Technical Parameters | |
Suitable bottle type | 15～500ml round、oblate、square、flat square bottle |
Size range | Bottleneck diameter 15～45mm |
Capacity | 50-100 bottles/min |
Total power | 3 kw |
Voltage | 220V 50HZ |
Air pressure | 0.6Mpa |
Machine dimension | 1200×500×1250mm |
Weight | 100KG |
Featuring strong compatibility, the sealing rate is adjustable to accommodate various aluminum foil sizes.
Equipped with fault self-diagnosis and comprehensive check-warning control functions, it ensures operational continuity and precision.
It achieves high electromagnetic conversion efficiency with low energy consumption, delivering an excellent sealing effect.
The system provides timely reminders and will halt automatically if the sealing rate deviates beyond the set parameters.
Utilizing an air-cooling mechanism, it offers effective cooling and an extended service life.
Fully automated and intelligently controlled, it harmonizes seamlessly with upstream and downstream processes.
No dedicated operator is required, resulting in significant labor cost savings.
